| Product Group | 356622 |
| End Standard | EN 1092-3 (Inlet), ISO 228-1 (Outlet) |
| Face To Face Standard | DIN 86211 |
| Remark | Connection: PN16 |
| Max temperature | +60°C |
| Throughput Direction | Straight |
| Pressure Rating | PN16 |
| End Type | Flanged/Threaded |
| Design Code | DIN 86211 |
| Standard | DIN |
| Application | Sea Water, Water |
| Size | 50 |
| Material Seat | NBR |
| Material Disc | Brass |
| Material Body | Bronze |
Fire Valve DN50 PN16
Straight type
Details
Bronze RG5 body soft sealing fire valve. Rising stem with bolted bonnet. Straight hose connection. Raised face flanged inlet, BSP male threaded outlet.
PARTSLIST AND DETAILS
Partslist
| No | Part | Material | Code |
|---|---|---|---|
| 1 | Body | Bronze | CC 491K |
| 2 | Bonnet | Bronze | CC 491K |
| 3 | Disc | Brass | CW 614N |
| 4 | Disc Sealing Ring | NBR | |
| 5 | Stem | Brass | CW 614N |
| 6 | Bonnet Gasket | Asbestos Free | |
| 7 | Gland Packing | Graphite | |
| 8 | Handwheel | Cast Iron | GG25 |
Details
| DN | Pressure Rating Id | nxdd | Hcd | Ø D |
|---|---|---|---|---|
| 50 | 16 | 4×18 | 125 | 165 |
| L | Kg | H | G | Ø M |
|---|---|---|---|---|
| 165 | 7 | 181 | 2″ | 140 |
