Image | Name & Description | Specification |
|---|---|---|
 |
Item No.: SHA/S 70-2 Single-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 – F10/F14 |
|
Item No.: SHA/S 70-1 Single-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 - F12 |
|
Item No.: SHA/S 63-4 Single-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 - F12 |
|
Item No.: SHA/S 63-3 Single-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 - F07/F10 |
|
Item No.: SHA/S 63-2 Single-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 - F12 |
|
Item No.: SHA/S 63-1 Single-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 - F07/F10 |
|
Item No.: SHA/S 40-190-2 Single-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 - F07/F10 |
|
Item No.: SHA/S 40-190-1 Single-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 - F07/F10 |
|
Item No.: SHA/S 40-78-4 Single-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 - F07/F10 |
|
Item No.: SHA/S 40-78-3 Single-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 - F05 |
|
Item No.: SHA/S 40-78-2 Single-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 - F07/F10 |
|
Item No.: SHA/S 40-78-1 Single-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 10.3 MPa acc. to EN 15714-4 Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 - F05 |
 |
Item No.: SHA/D 200-12 Double-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 6.0 MPa to 12.5 MPa Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 – F40 |
|
Item No.: SHA/D 200-11 Double-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 6.0 MPa to 12.5 MPa Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 – F30 |
|
Item No.: SHA/D 200-10 Double-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 6.0 MPa to 12.5 MPa Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 – F25 |
|
Item No.: SHA/D 200-9 Double-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 6.0 MPa to 12.5 MPa Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 – F40 |
|
Item No.: SHA/D 200-8 Double-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 6.0 MPa to 12.5 MPa Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 – F30 |
|
Item No.: SHA/D 200-7 Double-acting type hydraulic actuator. NBR O-Rings. |
Working Pressure: 6.0 MPa to 12.5 MPa Rotation: 90° ± 3° Seal: NBR O-Rings Mounting Bracket: ISO 5211 – F25 |
|
Item No.: SHA/D 200-6 Double-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 6.0 MPa to 12.5 MPa Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 – F40 |
|
Item No.: SHA/D 200-5 Double-acting type hydraulic actuator. Viton O-Rings. |
Working Pressure: 6.0 MPa to 12.5 MPa Rotation: 90° ± 3° Seal: Viton O-Rings Mounting Bracket: ISO 5211 – F30 |
